Rollback DB Schema step

Last updated on

The Rollback DB Schema step reverts previously applied database changesets on a target DB instance as part of a Harness pipeline. It is typically added after an Apply DB Schema step as part of a failure strategy or a dedicated rollback stage.

Before you begin​

  • Applied migrations: Rollback requires changesets previously applied by an Apply DB Schema step. Nothing can be rolled back on a fresh instance with no applied changesets.
  • Rollback scripts: Liquibase rollback requires that each changeset defines a rollback statement. Go to Automatic and Custom Rollback to understand when rollback scripts are required.
  • Tag (for rollback by tag): The target tag must exist in DATABASECHANGELOG. Go to Using Rollback Tags with Apply Schema to learn how tags are created.

Add the Rollback DB Schema step​

  1. In Harness, go to Database DevOps and select your project.
  2. Open your pipeline and select the stage where you want to configure rollback.
  3. Add a Custom Stage with a step group.
  4. Inside the step group, Add Step and choose Rollback DB Schema.
  5. Configure the step parameters described below.
  6. Select Apply Changes, then save and run the pipeline.

Step parameters​

DBDevOps Rollback DBSchema Step

  1. Name - Display name for the step. The step ID is derived from this name.
  2. Timeout - Maximum duration before the step times out. Default is 10m.
  3. Container Registry - Select the container registry connector that Harness uses to pull the migration container.
  4. Migration Type - Select Liquibase or Flyway depending on your schema's migration tool.
  5. Select DB Schema - Choose the DB Schema associated with the instance you want to roll back.
  6. Select DB Instance - Choose the DB Instance where the rollback will be executed.
  7. Specify rollback target - Choose how to identify the rollback target: rollback to a specific tag, rollback by count, or rollback to a target version (Flyway). Go to Rollback for Database Schemas for details on each method.
