Setup TechDocs for Catalog

Last updated on

This document will take you through detailed steps to enable and publish Markdown documentation for your Software Catalog using TechDocs.

What is TechDocs?​

TechDocs enables a docs-as-code approach where documentation lives alongside your source code in Git. Write docs in Markdown, commit them alongside your source code, and publish automatically. Your team can discover and access documentation instantly through the Docs tab in the Catalog; no more outdated wikis or scattered knowledge.

TechDocs is powered by the TechDocs Backstage Plugin and uses MkDocs as the static site generator to transform your Markdown files into beautiful, searchable documentation.

Key Benefits​

  • Docs-as-code: Version control your documentation alongside source code
  • Automatic publishing: Documentation updates automatically when you commit changes
  • Centralized discovery: All docs accessible through the Software Catalog
  • Markdown-based: Simple, developer-friendly format
  • Always up-to-date: Documentation evolves with your codebase

Setup TechDocs for Catalog​

To enable TechDocs for your component, you'll need to:

  1. Enable the TechDocs plugin for your entity in your catalog entity's YAML file
  2. Create documentation in Markdown format with an mkdocs.yml file
  3. Add the TechDocs annotation to specify where your documentation is located

Requirements

Your documentation files must be in Markdown format with an mkdocs.yml file present in the specified path.

Documentation Location Options​

You can add documentation for your component in two ways:

  1. Co-located with source code: Documentation lives in the same repository as your component's source code
  2. Separate location: Documentation is stored in a different repository or directory

Option 1: Co-located with Source Code​

When your documentation lives in the same repository as your component's source code:

Step 1: Create Documentation Structure​

Create a docs directory next to your catalog-info.yaml file:

├── catalog-info.yaml
└── docs
    └── index.md

Step 2: Create Documentation Content​

Inside the docs directory, create an index.md file with your documentation content. Here's a basic example:

# Welcome!

This is a basic example of documentation. It is intended to showcase some of the
features that TechDocs provides out of the box.

## Basic Markdown

Headings:

# h1

## h2

### h3

#### h4

##### h5

###### h6

Here is a bulleted list:

- Item one
- Item two
- Item Three

Check out the [Markdown Guide](https://www.markdownguide.org/) to learn more about how to
simply create documentation.

You can also learn more about how to configure and set up this documentation in Backstage,
[read the TechDocs Overview](https://backstage.io/docs/features/techdocs/).

## Table example

While this documentation isn't comprehensive, in the future it should cover the following
topics outlined in this example table:

| Topic   | Description                                                  |
| ------- | ------------------------------------------------------------ |
| Topic 1 | An introductory topic to help you learn about the component. |
| Topic 2 | A more detailed topic that explains more information.        |
| Topic 3 | A final topic that provides conclusions and lessons learned. |

## Learn more about MkDocs

TechDocs uses MkDocs as the static site generator. Visit https://www.mkdocs.org for more information about MkDocs.

Step 3: Add TechDocs Annotation​

Edit your catalog-info.yaml and add the TechDocs annotation in the metadata.annotations field:

metadata:
  annotations:
    backstage.io/techdocs-ref: dir:.

The dir:. annotation indicates that:

  • Documentation source code lives in the same location as the catalog-info.yaml file
  • The docs folder is a sibling of catalog-info.yaml (in the same directory)
