Add an AWS secrets manager

You can integrate AWS Secrets Manager to securely manage your Harness secrets.

Unlike AWS KMS, AWS Secrets Manager stores both secrets and their encrypted keys. In contrast, AWS KMS requires Harness to store the secret in its own store while retrieving the encryption keys from KMS. For more details on using AWS KMS as a Secrets Manager, refer to Add an AWS KMS Secrets Manager.

This guide explains the steps to add an AWS Secrets Manager in Harness."

important

You can only use Harness Built-in Secret Manager to store authentication credentials for access to the corresponding secret manager.

Storing credentials from one secret manager within another can result in complex and challenging situations. Moreover, these configurations might introduce vulnerabilities, posing potential security risks.

The Harness platform has several validations, including the disabling of self-references.

Things to Know

• If you're adding an AWS Secrets Manager on ROSA, set the environment variable AWS_REGION to the appropriate region, such as AWS_REGION=us-east-1.

Permissions: Test AWS Permissions

Harness uses the same minimum IAM policies for AWS secret manager access as the AWS CLI.

The AWS account you use for the AWS Secret Manager must have the following policies at a minimum:

{
    "Version": "2012-10-17",
    "Statement": {
        "Effect": "Allow",
        "Action": [
            "secretsmanager:Describe*",
            "secretsmanager:Get*",
            "secretsmanager:List*"
        ],
        "Resource": "*"
    }
}

These policies let you list secrets which will allow you to add the secret manager and refer to secrets, but it will not let you read secrets values.

The following policy list enables Harness to perform all the secrets operations you might need:

{
    "Version": "2012-10-17",
    "Statement": {
        "Effect": "Allow",
        "Action": [
          "secretsmanager:CreateSecret",
          "secretsmanager:DescribeSecret",
          "secretsmanager:DeleteSecret",
          "secretsmanager:GetRandomPassword",
          "secretsmanager:GetSecretValue",
          "secretsmanager:ListSecretVersionIds",
          "secretsmanager:ListSecrets",
          "secretsmanager:UpdateSecret",
          "secretsmanager:TagResource"
        ],
        "Resource": "*"
    }
}

Refer to the AWS documentation on Using Identity-based Policies (IAM Policies) for Secret Manager.

To test, use your AWS account and run the command aws secretsmanager list-secrets on the Harness Delegate host or any other host.

Step 1: Add a Secret Manager

This topic assumes you have a Harness Project set up. If not, refer to Create Organizations and Projects.

You can add a connector from any module in your Project in Project SETUP, or in your Organization, or Account Resources.

1. Select one of the following settings: Project, Organization, or Account.
2. Navigate to (Account/Organization/Project)-level Resources.
3. Click on Connectors.
4. Click on New Connectors.
5. Scroll down and check for Secret Manager.
6. Select AWS Secrets Manager.

Below is an example for adding to the Account.

note

For information on restrictions on names and maximum quotas, go to Quotas for AWS Secrets Manager.

Step 2: Overview

1. Enter a Name for your secret manager.
2. You can either update the ID or keep it the same as your secret manager's name. For more information, visit Entity Identifier Reference.
3. Provide a Description for your secret manager.
4. Enter Tags for your secret manager.
5. Select Continue.

Step 3: Credential Details

When setting up your AWS Secrets Manager in Harness, you can choose one of the following Credential Types for authentication:

1. AWS Access Key
2. Assume IAM Role on Delegate
3. Assume Role Using STS on Delegate
4. OIDC

General Settings for All Credential Types

1. Use "put-secret-value" Action to update secret value:

   • By default, Harness uses the UpdateSecret action to update secret values, which requires the secretsmanager:UpdateSecret permission for AWS Secrets Manager. Enable this option to use the PutSecretValue action instead, requiring the secretsmanager:PutSecretValue permission.

   note

   This item requires Harness Delegate version 24.11.84500. For more details about the Harness Delegate feature, please refer to the release notes.

2. Use as Default Secrets Manager:

   • Enable this option to set this Secrets Manager the default for all secret operations within your Harness account.

3. Force delete without recovery:

   • Force Delete Without Recovery: Enabling this option ensures that when a secret in AWS Secrets Manager is deleted, it will be permanently removed without any recovery window. The secret is deleted immediately, and recovery is not possible.

   • Recovery Window in Days (Optional): When specified, a delete request is made to AWS with the provided recovery window. Although the secret is deleted in Harness, it can be recovered in AWS Secrets Manager within the specified window. The recovery window can range from 7 to 30 days, with 30 days being the default if not specified.



     Important Note

     Force Delete without Recovery

     • If a user attempts to create the same secret (as an inline secret) again in Harness, an exception will be thrown.
     • Additionally, Force Delete Without Recovery cannot be enabled when a recovery window value is provided.


Credential Types

1. AWS Access Key

Use your AWS IAM user login credentials for authentication.

Prerequisites

• Access Key ID and Secret Access Key: Obtain these from the JSON Key Policy or the AWS IAM console under Encryption Keys.
• For detailed instructions, see Finding the Key ID and ARN in the AWS documentation.

Providing AWS Access Key ID

You have two options for adding the Access Key ID:

• Plaintext:

  • Enter the Access Key ID directly into the AWS Access Key ID field.

• Encrypted:

  • Click Create or Select a Secret.
  • In the dialog, create or select a Secret and enter the Access Key ID as the secret value.
  • Save and use the created secret for this configuration.

Providing AWS Secret Access Key

• Click Create or Select a Secret.
• Create or select an existing Secret with the Secret Access Key as its value.

Additional Fields

• Secret Name Prefix: Add a prefix to all secrets stored under this Secrets Manager. For example, using devops as the prefix results in secrets like devops/mysecret. This is not a folder name.
• Region: Select the appropriate AWS region for your Secrets Manager.

2. Assume IAM Role on Delegate

With this option, Harness uses the IAM role assigned to the AWS host running the selected Delegate for authentication.

Prerequisites

• Ensure the Delegate host has the appropriate IAM role assigned.

Additional Fields

• Refer to the Secret Name Prefix and Region settings described under the AWS Access Key section above.

3. Assume Role Using STS on Delegate

Harness uses AWS Security Token Service (STS) to assume a role. This option is commonly used for cross-account access or assuming roles within the same AWS account.

Prerequisites

• Configure an IAM role in the target AWS account.

Required Fields

• Role ARN: Enter the Amazon Resource Name (ARN) of the role you want to assume.
• External ID: If provided by the account administrator, enter the External ID for additional security. See AWS External ID documentation for more details.
• Assume Role Duration: Specify the session duration for the assumed role. For more information, refer to the AssumeRole API documentation.

Additional Fields

• Refer to the Secret Name Prefix and Region settings described under the AWS Access Key section above.

4. OIDC - OpenID Connect

Harness uses OpenID Connect (OIDC) to authenticate and authorize users. This option is commonly used for secure identity federation across different applications or cloud platforms, enabling seamless authentication and access management.

• Configure an IAM role in the target AWS account.

• Once your configuration is complete, set the IAM role and region below to proceed with the setup, as shown in the image above.

An additional step before proceeding.

Connectivity mode

This additional step allows you to select the connectivity mode.

Once you have selected OIDC, you will be able to select connectivity mode, based on the requirement you can select the provider that can be either connect through a delegate or through Harness platform.

Step 4: Setup Delegates

In Setup Delegates, enter Selectors for specific Delegates that you want to allow to connect to this connector.

Step 5: Test Connection

Once the Test Connection succeeds, select Finish. You can now see the connector in Connectors.

Reference JSON secrets

Harness allows you to manage the lifecycle of your secrets independently by referencing JSON secrets in the vault.

For example, you can store a secret in vault with the following JSON.

{
  "key1": "value1",
  "key2": {
    "key21": "value21",
    "key22": "value22"
  },
  "key3": {
    "key31": {
      "key311": "value311"
    }
  }
}

Here are sample outputs for the respective JSONPath from the above JSON file:

test-secret (without any # key)

{
  "key1": "value1",
  "key2": {
    "key21": "value21",
    "key22": "value22"
  },
  "key3": {
    "key31": {
      "key311": "value311"
    }
  }
}

test-secret#key1

"value1"

test-secret#key2

{
  "key21": "value21",
  "key22": "value22"
}

test-secret#key3

{
  "key31": {
    "key311": "value311"
 }
}

test-secret#key3.key31

{
  "key311": "value311"
}

test-secret#key3.key31.key311

 "value311"

info

You cannot use a JSON XPath for nested keys in expressions. For example, <+secrets.getValue("account.YOUR_SECRET_MANAGER://myVault/harness/testpath/example")>.

Harness provides limited support for keys that include dots. Keys with dots only work when the key is present at first level in the JSON. For example:

{
  "key.abc": "some-value",
  "key": {
    "nested.key1": "some-value"
  },
  "key.pqr": {
    "nestedKey": "some-value"
  },
  "pqr.xyz": "some-value",
  "pqr": {
    "xyz": "some-nested-value"
  }
}

Here are sample outputs for the respective JSONPath from the above JSON file:

• /path/to/secret#key.abc returns some-value.
• /path/to/secret#key.pqr returns {"nestedKey": "some-value"}.
• /path/to/secret#key.nested.key1 and key.pqr.nestedKey are not supported.
• /path/to/secret#pqr.xyz returns some-nested-value and not some-value. (Hierarchical paths take precedence over keys with dots.)

warning

Harness does not recommend using keys that include dots and might deprecate support in future releases.
